- Optional Thumbs to easily pick up and move large debris.
- High-back Seat for more comfortable and easy operation.
- Open Platform allows you to get on and off the unity easily.
- Ergonomically Positioned Levers for comfort and easy operation.
Groundbreaker® Backhoes
BH65
Heavy-Duty
Greater Visibility
Curved-boom design allows you to dig with greater visibility and control.
Fits Many Tractors
Subframe kits and three-point mounts available for many tractor models.
Industry-leading 2-year Tractor Protection
Peace of mind with an unmatched 2-year tractor warranty when a properly installed Woods subframe is purchased from Woods.
Read More
Additional Features
Backed by a 2-year warranty
Some colors only available on select models.
Specifications
| Product Tier |
Heavy-Duty |
|---|---|
| Tractor PTO HP |
15-30 |
| Digging Depth - 2' Flat Bottom (in | ft) |
78 ,6.5 |
| Digging Depth - 8 ft Flat Bottom (in) |
52 |
| Reach from Swing Pivot (in) |
102 |
| Loading Height (in) |
60 |
| Loading Reach (in) |
33.5 |
| Transport Height (in) |
66.5 |
| Transport Length (in) |
42 |
| Approx. Weight - Frame Only (lbs) |
695 |
| Swing Arc (degrees) |
150 |
| Stabilizer Spread - Up (transport) (in) |
52 |
| Stabilizer Spread - Down (operating) (in) |
83 |
| Relief Pressure (psi) |
2,030 |
| Bucket Digging Force (lbs) |
2,800 |
| Dipperstick Digging Force (lbs) |
1 ,590 |
| Bucket Rotation (degrees) |
180 |
| Trenching Bucket Widths (in) |
9 ,12 ,16 |
| Thumb |
Optional mechanical |
| Flip-Over Stabilizer Pads |
Standard |
| Stabilizer Street Pads |
Optional |
| Ditching Bucket |
N/A |
| Cemetery / Bellhole Bucket |
N/A |
| Warranty |
2 year limited, including the tractor |
| Woods C® |
Tractor Compatibility
| Tractor Make | Tractor Model |
|---|---|
| Tractor Make | Tractor Model |
| Loading... | |
